Power Integrations Debuts Support for Planar Magnetics in PI Expert Power Supply Design Tool

Power Integrations (NASDAQ: POWI), the chief in high-voltage built-in circuits for energy-efficient energy conversion, right this moment launched a brand new perform in PI Expert™, the highly effective on-line design device that robotically generates optimized energy provide designs based mostly on customers’ specs. PI Expert now encompasses a planar magnetics builder that generates an application-specific planar transformer design full with printed circuit board (PCB) manufacturer-ready documentation and Gerber recordsdata. The newest model of PI Expert now additionally consists of assist for Power Integrations’ complete InnoSwitch™3 flyback switcher IC household.

This press launch options multimedia. View the total launch right here: https://www.businesswire.com/news/home/20221025005281/en/

Power Integrations Debuts Support for Planar Magnetics in PI Expert Power Supply Design Tool (Photo: Business Wire)

Trevor Hiatt, director of channel advertising and marketing at Power Integrations stated: “Planar transformers facilitate low-profile flyback energy provides. With our new planar magnetics builder, designers can incorporate a complicated low-profile transformer in minutes. No different design device can do that.”

The magnetics designer perform in PI Expert gives full planar transformer info together with stack specification, vertical and horizontal PCB development, hint parameters, present density info and layer resistance. The device robotically incorporates user-specified creepage and clearance distances mandatory to fulfill security isolation requirements. An intuitive GUI gives vertical and horizontal stack development and a chicken’s eye view for all layers. The device additionally outputs detailed manufacturing info of the planar answer, enabling customers to go immediately from design to fabrication.

The device gives a complete database of planar cores and elements to simplify design and can even settle for customized core geometries. PI Expert robotically optimizes the planar transformer design to match the ability provide specification, incorporating extra winding layers and adjusting hint geometries as acceptable.

PI Expert leverages a long time of PI’s mixed energy provide design experience and is utilized by tens of 1000’s of world engineers yearly. For extra info, entry the device at energy.com or watch this video.
